Secap Jet 1 High Volume / Production Console Address Printer

Secap Jet 1,address printers,envelope printers,usps postal barcode printers,postcard printers,address printer,envelope printer,postcard printer

Secap Jet 1 - J160 Configuration (6" Print Area)

The Secap Jet 1 delivers unmatched performance and productivity. Now there is a high quality addressing and imaging system that maximizes output, improves productivity and optimizes the efficiency of your mailing operations. The system provides true synchronization among the transport base, feeder and conveyor reducing manual intervention and increasing overall output.

The Secap Jet 1 high production addressing and imaging system has been designed for the mailing professional. The Secap Jet 1 system can be configured with 3", 4.5"or 6"of print. The system provides users the ultimate solution for improving productivity by offering true synchronization between the feeder, base and conveyor reducing the need for operator intervention. Combine the heavy-duty vacuum transport base with the high capacity feeder to process large volumes of media eliminating the need for additional operators. The high capacity feeder can easily handle 2000 #10 envelopes at one time.

The Secap Jet 1 vacuum base is extremely flexible and can be utilized in-line with a tabber, inserter and other equipment that requires a transport. With its fully integrated speed control, the speed of the entire system can be adjusted with the turn of a single master dial.

Secap Jet 1 - HP C8842A Versatile Black Ink Video
Secap Jet 1 - Secap Picaso Ink Video

Technical Specifications

Throughput
Up to 30,000 #10 envelopes/hour in super draft quality
Up to 22,000 #10 envelopes/hour in draft quality
Up to 15,000 #10 envelopes/hour in letter quality
Up to 7,500 #10 envelopes/hour in executive quality

Print Area
Configurations available:
· 3" of print using (2) 1-1/2" print banks
· 4.5" of print using (1) 1-1/2" and (1) 3" print banks or (3) 1-1/2" print banks
· 6" of print using (2) 3" print banks or (4) 1-1/2" print banks

Address Area:
3" of width configurable up to 6" in 1-1/2" print banks

Media Size
Width: 3” minimum to 12.25” maximum
Length: 2” minimum to 14” maximum
Thickness: From .002” thick to .625”

Print Resolution
150, 200, 300, 600 dpi horizontal, 600 dpi vertical

Print Modes
Super Draft, Draft, Letter, Executive

Fonts
Internal: 12 scaleable fonts; 4-30 points,
Attributes: Regular, Bold, Invert, Outline and 5 widths

Barcode
USPS, Planet Code Barcode, EAN-13/UPC-A Internal

Interface
Centronics Parallel or USB

Driver Compatibility
Windows 95, 98, 2000, NT, ME and XP

Printhead/InkJet Cartridge
Standard HP 45 Cartridge
Versatile Black
Picaso Ink
Spot Color: Yellow, Blue, Green & Red

Physical Characteristics:
Dimensions:
Main vacuum base: 43”L x 24”W x 32-37”H
Dryer base: 30”L x 24”W x 32-37”H
Feeder base: 24”L x 24”W x 32-37”H
Ultrafeed: 85”L x 18”W x 32-37”H

Weight: Depends on combination of components

Power:
Printer base: 220 Vac, 60 Hz, single phase, 20 Amp
Plug Style: NEMA L6-20, Two pole, Three wire (opt.)
Heater base: 220 Vac, 60 Hz, single phase, 30 Amp
Plug Style: NEMA L6-30P, Two pole, Three wire

Certification: TUV

	Model #	Description	Suggested Retail
	J-160	Base Unit	$37,575.00
Base Unit with Heavy Duty Friction Feeder (S) Configurations
	J160S	Includes synchronized SE1200ij Friction Feeder and Feeder Cabinet	$43,305.00
	J160S-9S	Includes SE1200ij Feeder, Feeder Cabinet and a 9' variable speed conveyor	$47,579.00
	J160S-9U	Includes SE1200ij Feeder, Feeder Cabinet, 9' UltraSort conveyor	$50,595.00
	J160S-9SD	Includes SE1200ij Feeder, Feeder Cabinet and a 9' variable speed conveyor and a dryer base with heater	$56,239.00
	J160S-9UD	Includes SE1200ij Feeder, Feeder Cabinet and a 9' UltraSort conveyor and a dryer base with heater	$59,390.00
Base Unit with UltraFeed (U) Configurations
	J160U	Includes Secap UltraFeed Feeder	$46,119.00
	J160U-9S	Includes Secap UltraFeed Feeder and a 9' variable speed conveyor	$51,179.00
	J160U-9U	Includes Secap UltraFeed Feeder and a 9' UltraSort conveyor	$53,995.00
	J160U-9SD	Includes Secap UltraFeed Feeder, a dryer base with heater, and a 9' conveyor	$59,615.00
	J160U-9UD	Includes Secap UltraFeed Feeder, a dryer base with heater, and a 9' UltraSort conveyor	$62,429.00
