| First Page Output Time |
Color: 10.5 seconds from an idle, ready
state on plain paper
Monochrome: 9 seconds from an idle,
ready state on plain paper |
|
| Print Method |
Electrophotographic, single pass, digital
envelope press |
|
| Print Speed |
Out the tray
Color: up to 36 ppm
Monochrome: up to 40 ppm
Envelope Feeder: 60 envelopes |
|
| Recommended Duty Cycle |
150,000 prints per month maximum (industry
standard letter/A4 at 5%) |
|
| Resolution |
600 x 1200 dpi |
|
| Warm-up Time |
Up to 85 seconds |
|
|
|
Consumables
| In-Box Cartridges |
Printer ships with one each cyan, magenta,
yellow and black toner cartridge; cyan, magenta, yellow and
black image drum; waste toner box, fuser unit, and transfer belt |
|
|
Electrical
| Power Consumption |
Operating: 750W
Standby: 200W
Power
Save Mode: 55W |
|
| Power Requirements |
120 (110 – 127) VAC; 60 Hz ± 2 Hz |
|
|
Environmental
| Humidity |
Operating: 20-80% RH
Non-operating:
10-90% RH
Best Print Quality: 50-70% RH |
|
| Noise Levels |
Operating: 53 dB
Standby: 40 dB
Power
Save Mode: 40 dB |
|
| Temperature Requirements |
Operating: 50-90° F (10-32° C)
Non-operating: 32-110° F (0-43° C)
Best Print Quality: 63-80°
F (17-26° C) |
|
|
Hardware and Software Capabilities
| Memory |
1 GB standard |
|
| Operating System
Compatibility |
Windows: Windows® XP Professional, XP Home,
2003 Server; Windows 98, 98 SE, ME, NT® 4.0 Workstation, NT 4.0
Server (SP6 or later), 2000 Workstation (SP3 or later), 2000
Professional (SP3 or later), 2000 Server (SP3 or later), 2000
Advanced Server (SP3 or later) Citrix® MetaFrame® – Windows 2000
Server (ServicePack4) with Citrix MetaFrame XP® Presentation
Server Feature Release 3, Windows Server 2003 Standard Edition
with Citrix MetaFrame XP Presentation Server Feature Release 3;
Macintosh Mac® OS 9.x, Mac O |
|
| Printer Languages |
Adobe PostScript 3, PDF v.1.4 Emulations:
PCL®5c, PCL 6, IBM PPR, EPSON FXDirect PDF Printing (Windows
environment only) |
|
| Printer Management |
Printer Drivers, Color Correct Utility,
Color Swatch Utility, PDF Direct Print, Profile Assistant, PS
Gamma Adjuster, Storage Device Manager, Admin Manager/Quick
Setup, LPR Utility, Network Printer Status |
|
| Processor Type |
PowerPC 750FX, 800 MHz |
|
|
Interface Support
| Ethernet Protocols |
TCP/IP, Netware and Ethertalk. TCP/IP
includes ARP, IP, ICMP, TCP, UDP, LPR, FTP, TELNET, HTTP(IPP),
BOOTP, DHCP, SNMP, DNS, SSL/TLS, JetDirect protocols Netware
includes 3.x, 4.x, 5.x, and 6.x with full NDS and NDPS support –
PServer, RPrinter, NDPS supported via dedicated NDPS Gateway.
EtherTalk; ELAP, AARP, DDP, AEP, NBP, ZIP, RTMP, ATP, PAP. |
|
| Standard |
10/100-TX Ethernet, High-speed USB v2.0,
Parallel |
|
|
Paper Handling
| Delivery Stacker |
Variable speed conveyor belt |
|
| Envelope Input Feeder |
750 #10 envelopes (4.125" x 9.5" or 105 mm x
242 mm)
Min: 5.125" x 4.125" or 130.2 mm x 104.8 mm (W x H)
Max: 12.5" x 13" or 318 mm x 330 mm (W x H) |
|
| Paper Sizes Supported |
Tabloid extra (12" x 18"), tabloid, legal,
letter, executive, index cards, A3, A3 wide, A3, A4, A5, A6, B4,
B5, C5 |
|
| Paper Weights |
Envelopes
Trays 1: 75-216 gsm; 50 lb.
text to 80 lb. cover
Duplexer: 75-188 gsm; 50 lb. text to 80
lb. text |
|
| Print Media |
Plain paper, letterhead, glossy stock,
coated, uncoated |
|
| Standard Paper Input |
530 sheets (universal tray) |
|
|
Physical
| Dimensions (WxDxH) |
including delivery conveyer 92" x 24.4" x
18.2" (233 cm x 62.0 cm x 46.2 cm) |
|
| Type |
Digital envelope press with internal Adobe
PostScript controller |
|
| Weight |
152 lb. (69.0 kg) without options |
|
|
Typefaces
- 136 Adobe PostScript Type 1 typefaces, 86
scalable PCL fonts, 1 bitmap font, 10 TrueType® fonts, OCR A/B,
USPS Barcode
|
